What is Microscopic Cross-section – Definition

The standard unit for measuring the microscopic cross-section (σ-sigma) is the barn, which is equal to 10-28 m2. Microscopic cross-sections are used to express the likelihood of particular nuclear interaction. Material Properties

Definition of Cross-section

nuclear cross-sections, microscopic cross-sectionsIn general, the cross-section is an effective area that quantifies the likelihood of certain interaction between an incident object and a target object. The cross-section of a particle is the same as the cross section of a hard object, if the probabilities of hitting them with a ray are the same.

For a given event, the cross section σ is given by

σ = μ/n


  • σ is the cross-section of this event [m2],
  • μ is the attenuation coefficient due to the occurrence of this event [m-1],
  • n is the density of the target particles [m-3].

In nuclear physics, the nuclear cross section of a nucleus is commonly used to characterize the probability that a nuclear reaction will occur. The cross-section is typically denoted σ and measured in units of area [m2]. The standard unit for measuring a nuclear cross section is the barn, which is equal to 10−28 m² or 10−24 cm². It can be seen the concept of a nuclear cross section can be quantified physically in terms of “characteristic target area” where a larger area means a larger probability of interaction.

Nuclear Radius
Typical nuclear radii are of the order 10−14 m. Assuming spherical shape, nuclear radii can be calculated according to following formula:

r = r0 . A1/3

where r0 = 1.2 x 10-15 m = 1.2 fm

If we use this approximation, we therefore expect the geometrical cross-sections of nuclei to be of the order of πr2 or 4.5×10−30 m² for hydrogen nuclei or 1.74×10−28 m² for 238U nuclei.

Since there are many nuclear reaction from the incident particle point of view, but, in nuclear reactor physics, neutron-nuclear reactions are of particular interest. In this case the neutron cross-section must be defined.

Total Cross-section
In general, nuclear cross-sections can be measured for all possible interaction processes together, in this case they are called total cross-sections (σt). The total cross section is the sum of all the partial cross sections such as:

σt = σs + σi + σγ + σf + ……

The total cross-section measures the probability that an interaction of any type will occur when neutron interacts with a target.

Interaction of Neutrons with Matter

Neutron Interactions

Neutrons are neutral particles, therefore they travel in straight lines, deviating from their path only when they actually collide with a nucleus to be scattered into a new direction or absorbed. Neither the electrons surrounding (atomic electron cloud) a nucleus nor the electric field caused by a positively charged nucleus affect a neutron’s flight. In short, neutrons collide with nuclei, not with atoms.

Neutrons may interact with nuclei in one of following ways:

See also: Neutron Nuclear Reactions

See also: Direct Nuclear Reactions

See also: Compound Nucleus Reactions

Neutron - Nuclear Reactions

Microscopic Cross-section

The extent to which neutrons interact with nuclei is described in terms of quantities known as cross-sections. Cross-sections are used to express the likelihood of particular interaction between an incident neutron and a target nucleus. It must be noted this likelihood do not depend on real target dimensions. In conjunction with the neutron flux, it enables the calculation of the reaction rate, for example to derive the thermal power of a nuclear power plant. The standard unit for measuring the microscopic cross-section (σ-sigma) is the barn, which is equal to 10-28 m2. This unit is very small, therefore barns (abbreviated as “b”) are commonly used.

The cross-section σ can be interpreted as the effective ‘target area’ that a nucleus interacts with an incident neutron. The larger the effective area, the greater the probability for reaction. This cross-section is usually known as the microscopic cross-section.

The concept of the microscopic cross-section is therefore introduced to represent the probability of a neutron-nucleus reaction. Suppose that a thin ‘film’ of atoms (one atomic layer thick) with Na atoms/cm2 is placed in a monodirectional beam of intensity I0. Then the number of interactions C per cm2 per second will be proportional to the intensity I0 and the atom density Na. We define the proportionality factor as the microscopic cross-section σ:

σt = C/Na.I0

In order to be able to determine the microscopic cross section, transmission measurements are performed on plates of materials. Assume that if a neutron collides with a nucleus it will either be scattered into a different direction or be absorbed (without fission absorption). Assume that there are N (nuclei/cm3) of the material and there will then be N.dx per cm2 in the layer dx.
Only the neutrons that have not interacted will remain traveling in the x direction. This causes the intensity of the uncollided beam will be attenuated as it penetrates deeper into the material.


Then, according to the definition of the microscopic cross section, the reaction rate per unit area is Nσ Ι(x)dx. This is equal to the decrease of the beam intensity, so that:

-dI = N.σ.Ι(x).dx


Ι(x) = Ι0e-N.σ.x

It can be seen that whether a neutron will interact with a certain volume of material depends not only on the microscopic cross-section of the individual nuclei but also on the density of nuclei within that volume. It depends on the N.σ factor. This factor is therefore widely defined and it is known as the macroscopic cross section.

The difference between the microscopic and macroscopic cross sections is extremely important. The microscopic cross section represents the effective target area of a single nucleus, while the macroscopic cross section represents the effective target area of all of
the nuclei contained in certain volume.

Microscopic cross-sections constitute a key parameters of nuclear fuel. In general, neutron cross-sections must be calculated for fresh fuel assemblies usually in two-Dimensional models of the fuel lattice.

The neutron cross-section is variable and depends on:

  • Target nucleus (hydrogen, boron, uranium, etc.). Each isotop has its own set of cross-sections.
  • Type of the reaction (capture, fission, etc.). Cross-sections are different for each nuclear reaction.
  • Neutron energy (thermal neutron, resonance neutron, fast neutron). For a given target and reaction type, the cross-section is strongly dependent on the neutron energy. In the common case, the cross section is usually much larger at low energies than at high energies. This is why most nuclear reactors use a neutron moderator to reduce the energy of the neutron and thus increase the probability of fission, essential to produce energy and sustain the chain reaction.
  • Target energy (temperature of target material – Doppler broadening). This dependency is not so significant, but the target energy strongly influences inherent safety of nuclear reactors due to a Doppler broadening of resonances.

Microscopic cross-section varies with incident neutron energy. Some nuclear reactions exhibit very specific dependency on incident neutron energy. This dependency will be described on the example of the radiative capture reaction. The likelihood of a neutron radiative capture is represented by the radiative capture cross section as σγ. The following dependency is typical for radiative capture, it definitely does not mean, that it is typical for other types of reactions (see elastic scattering cross-section or (n,alpha) reaction cross-section).

The capture cross-section can be divided into three regions according to the incident neutron energy. These regions will be discussed separately.

  • 1/v Region
  • Resonance Region
  • Fast Neutrons Region

Table of cross-sections

Neutron - Nuclear Reactions
Uranium 238. Neutron absorption and scattering. Comparison of cross-sections.
Uranium 238. Comparison of cross-sections.
Gadolinium 155 and 157. Comparison of radiative capture cross-sections.
Gadolinium 155 and 157. Comparison of radiative capture cross-sections.
Source: JANIS (Java-based Nuclear Data Information Software); The JEFF-3.1.1 Nuclear Data Library
1/v Law
For thermal neutrons (in 1/v region), absorption cross sections increases as the velocity (kinetic energy) of the neutron decreases.
Source: JANIS 4.0
Neutron Elastic Scattering - Cross-section Example
To be an effective moderator, the probability of elastic reaction between neutron and the nucleus must be high. In terms of cross-sections, the elastic scattering cross section of a moderator’s nucleus must be high.

See also: Elastic Scattering Reaction

Elastic scattering cross-sections for light elements
Elastic scattering cross-sections for light elements are more or less independent of neutron energy up to 1 MeV. Source: JANIS (Java-based Nuclear Data Information Software); The JEFF-3.1.1 Nuclear Data Library
Elastic scattering cross-sections for heavy elements
For intermediate and heavy elements, the elastic cross-section is constant at low energy with some specifics at higher energy.
Inelastic Scattering - Cross-section Example
See also: Inelastic Scattering Reaction
Inelastic Neutron Scattering Cross-section
Inelastic scattering plays an important role in slowing down neutrons especially at high energies and by heavy nuclei.
Charged Particle Reaction - Cross-section Example
Boron 10. Comparison of total cross-section and cross-section for (n,alpha) reactions. Source: JANIS (Java-based Nuclear Data Information Software); The JEFF-3.1.1 Nuclear Data Library
Boron 10. Comparison of total cross-section and cross-section for (n,alpha) reactions.
Source: JANIS (Java-based Nuclear Data Information Software); The JEFF-3.1.1 Nuclear Data Library


This reaction is the most important (n,alpha) reaction of isotope 10B with thermal neutrons. This reaction can be used as in the case of neutron absorbers (chemical shim, burnable absorbers or control rods), and in the case of neutron converters (neutron detectors), because its cross-section is very high and produces energetic alpha particles.

(n,alpha) reactions of 10B


This is a reaction allowing detection of neutrons. The reaction cross-section for thermal neutrons is σ = 925 barns and the natural lithium has abundance of 6Li 7,4%.

See also – Charged Particle Reactions

Nuclear Fission - Cross-section Example
See also: Nuclear Fission
Fissile / Fertile Material Cross-sections
Fissile / Fertile Material Cross-sections. Comparison of total fission cross-sections.
Source: JANIS (Java-based Nuclear Data Information Software)

1/v Region

In the common case, the cross section is usually much larger at low energies than at high energies. For thermal neutrons (in 1/v region), also radiative capture cross-sections increase as the velocity (kinetic energy) of the neutron decreases. Therefore the 1/v Law can be used to determine shift in capture cross-section, if the neutron is in equilibrium with a surrounding medium. This phenomenon is due to the fact the nuclear force between the target nucleus and the neutron has a longer time to interact.

sigma_a sim frac{1}{v}}} sim frac{1}{sqrt{E}}}}} sim frac{1}{sqrt{T}}}}}

This law is aplicable only for absorbtion cross-section and only in the 1/v region.

Example of cross- sections in 1/v region:

The absorbtion cross-section for 238U at 20°C = 293K (~0.0253 eV) is:

sigma_a(293K) = 2.68b .

The absorbtion cross-section for 238U at 1000°C = 1273K is equal to:

Neutron Cross-section - 1-v law

This cross-section reduction is caused only due to the shift of temperature of surrounding medium.

Resonance Region

The largest cross-sections are usually at neutron energies, that lead to long-lived states of the compound nucleus. The compound nuclei of these certain energies are referred to as nuclear resonances and its formation is typical in the resonance region. The widths of the resonances increase in general with increasing energies. At higher energies the widths may reach the order of the distances between resonances and then no resonances can be observed. The narrowest resonances are usually compound states of heavy nuclei (such as fissionable nuclei).

Since the mode of decay of the compound nucleus does not depend on the way the compound nucleus was formed, the nucleus sometimes emits a gamma ray (radiative capture) or sometimes emits a neutron (scattering). In order to understand the way, how a nucleus will stabilize itself, we have to understand the behaviour of compound nucleus.

The compound nucleus emits a neutron only after one neutron obtains an energy in collision with other nucleon greater than its binding energy in the nucleus. It have some delay, because the excitation energy of the compound nucleus is divided among several nucleons. It is obvious the average time that elapses before a neutron can be emitted is much longer for nuclei with large number of nucleons than when only a few nucleons are involved. It is a consequence of sharing the excitation energy among a large number of nucleons.

This is the reason the radiative capture is comparatively unimportant in light nuclei but becomes increasingly important in the heavier nuclei.

It is obvious the compound states (resonances) are observed at low excitation energies. This is due to the fact, the energy gap between the states is large. At high excitation energy, the gap between two compound states is very small and the widths of resonances may reach the order of the distances between resonances. Therefore at high energies no resonances can be observed and the cross section in this energy region is continuous and smooth.

The lifetime of a compound nucleus is inversely proportional to its total width. Narrow resonances therefore correspond to capture while the wider resonances are due to scattering.

See also: Nuclear Resonance

Fast Neutrons Region

The radiative capture cross-section at energies above the resonance region drops rapidly to very small values. This rapid drop is caused by the compound nucleus, which is formed in more highly-excited states. In these highly-excited states it is more likely that one neutron obtains an energy in collision with other nucleon greater than its binding energy in the nucleus. The neutron emission becomes dominant and gamma decay becomes less important. Moreover, at high energies, the inelastic scattering and (n,2n) reaction are highly probable at the expense of both elastic scattering and radiative capture.

Doppler Broadening of Resonances

In general, Doppler broadening is the broadening of spectral lines due to the Doppler effect caused by a distribution of kinetic energies of molecules or atoms. In reactor physics a particular case of this phenomenon is the thermal Doppler broadening of the resonance capture cross sections of the fertile material (e.g. 238U or 240Pu) caused by thermal motion of target nuclei in the nuclear fuel.

The Doppler broadening of resonances is very important phenomenon, which improves reactor stability, because it accounts for the dominant part of the fuel temperature coefficient (the change in reactivity per degree change in fuel temperature) in thermal reactors and makes a substantial contribution in fast reactors as well. This coefficient is also called the prompt temperature coefficient because it causes an immediate response on changes in fuel temperature. The prompt temperature coefficient of most thermal reactors is negative.

See also: Doppler Broadening

Doppler effect
Doppler effect improves reactor stability. Broadened resonance (heating of a fuel) results in a higher probability of absorbtion, thus causes negative reactivity insertion (reduction of reactor power).
